Spectral Blue

CL-series

CL-series

Low-profile, corner-mounted blue light disinfection device

Model

Features

  • MWHI blue light disinfection
  • White light mode (DUAL models only)
  • Fixed installation
  • External LED drivers

Tests & Certifications

  • CE
  • RoHS
  • Blue Light Hazard

View full details

Product description and specifications

The SPECTRAL CL ("Corner-Linear") blue light disinfection device: The compact size and smart corner-mounting profile makes the CL-series ideal for machines, restrooms, corridors, storage rooms, or any other space where a space-saving disinfection & general lighting device is needed. With two different power and length options and selectable 30 or 60 degrees light angle you will find suitable versions to all your disinfection needs.

The CL-series is also available in single-mode, without white light.

Name: SPECTRAL CL35 SPECTRAL CL65
Ordering code: Dual-mode 13011
Single-mode 19051
Dual-mode 13181
Single-mode 19121
Features MWHI blue light disinfection White (dual-mode only) MWHI blue light disinfection White (dual-mode only)
Power consumption: 35 W 15 W 65 W 30 W
Colour temperature: - 4000 K - 4000 K
CRI: - >90 - >90
Weight: 0,7 kg 0,8 kg
Dimensions: L660 x H42 x W48 mm L1220 x H42 x W48 mm
Average lifetime: 50 000 h
Operating temperature: 0 - +40°C
Beam angle: 120°
Protection class: IP40/20
Materials: Aluminium + Plastic
LED driver(s): Outside device; Single: 1 driver. Dual: 2 drivers.
Installation: Screws or mounting bracket. Light angle can be selected as 30 degrees or 60 degrees relative to vertical axis.
Control method: DALI/on/off
Warranty: 1 year. Extended warranty available.
Certifications: CE
BLH risk group according to IEC 62471: With clear light cover: RG2 (moderate risk) ≤ 252 mm, RG1 (low risk) > 252 mm

Patented Multi-Wavelength, High-Intensity (MWHI) Technology

  • Utilizes 405 nm + 450 nm visible blue light
  • 5-10 x more powerful than single-wavelength applications
  • Effective against the widest range of microbes
Learn more about MWHI technology

Continuous Disinfection

  • Use Spectral Blue whenever the rooms is unoccupied for the maximum effect
  • Even short bursts during the day can suppress microbial growth
  • In continuous use, Spectral Blue pushes the room's bioburden down and then keeps it down

Learn more about continuous disinfection

Works Against Biofilms, Multi-resistant Strains And Spore-formers

  • Works against bacteria, yeasts and molds - also through biofilms
  • Does not promote the development of antimicrobial resistance
See test results

Request Free 3D Disinfection Planning

The easiest way to get started - we can create a 3D model of your site or room and optimize the type and number of Spectral Blue MWHI® devices for your specific needs.
