Spectral Blue
CL-series
CL-series
Low-profile, corner-mounted blue light disinfection device
The SPECTRAL CL ("Corner-Linear") blue light disinfection device: The compact size and smart corner-mounting profile makes the CL-series ideal for machines, restrooms, corridors, storage rooms, or any other space where a space-saving disinfection & general lighting device is needed. With two different power and length options and selectable 30 or 60 degrees light angle you will find suitable versions to all your disinfection needs.
The CL-series is also available in single-mode, without white light.
🖶 Print datasheet
| Name: | SPECTRAL CL35 | SPECTRAL CL65 | ||
| Ordering code: | Dual-mode 13011 Single-mode 19051 |
Dual-mode 13181 Single-mode 19121 |
||
| Features | MWHI blue light disinfection | White (dual-mode only) | MWHI blue light disinfection | White (dual-mode only) |
| Power consumption: | 35 W | 15 W | 65 W | 30 W |
| Colour temperature: | - | 4000 K | - | 4000 K |
| CRI: | - | >90 | - | >90 |
| Weight: | 0,7 kg | 0,8 kg | ||
| Dimensions: | L660 x H42 x W48 mm | L1220 x H42 x W48 mm |
||
| Average lifetime: | 50 000 h | |||
| Operating temperature: | 0 - +40°C | |||
| Beam angle: | 120° | |||
| Protection class: | IP40/20 | |||
| Materials: | Aluminium + Plastic | |||
| LED driver(s): | Outside device; Single: 1 driver. Dual: 2 drivers. | |||
| Installation: | Screws or mounting bracket. Light angle can be selected as 30 degrees or 60 degrees relative to vertical axis. | |||
| Control method: | DALI/on/off | |||
| Warranty: | 1 year. Extended warranty available. | |||
| Certifications: | CE | |||
| BLH risk group according to IEC 62471: | With clear light cover: RG2 (moderate risk) ≤ 252 mm, RG1 (low risk) > 252 mm | |||
Product specifications are subject to change.
